Precision mold
Resin sealing mold for semiconductor
| Product | Description |
|---|---|
 | Production and prototyping of various molds such as discrete, IC, power system, lenses etc Provide molds that adhere to product specifications. |
Injection mold
| Product | Description |
|---|---|
 | Connectors, relays, cases, bases related to mold production and parts processing are possible. If it is a palm-sized part, we will respond to your consultation. |
Drawing mold / bending type
| Product | Description |
|---|---|
| Improvement of part precision is indispensable for punch die clearance setting, judgment surface and bending surface finish in punching and bending type. The yield can be improved by NFT precision polishing technology and micron processing. |
Peripheral parts for molding · Jig
| Product | Description |
|---|---|
| We can manufacture not only our own molds but also up to parts mold jigs for each manufacturer's mold. (Can also be changed to improve specifications) Molded prototype MOLD bases and plunger units have been converted into jigs and molds made by other manufacturers can be prototyped (molded). |
Resin sealing device for semiconductor
Auto mold
Product name: Across 2by X series
| Product | Description |
|---|---|
 | A mass production model that can carry multiple presses. (Maximum 5 units) By adopting a linear motor for the conveyance drive, we realized the fastest machine time of 15 seconds. Switching to other types can be done in 30 minutes in the shortest for conversion support. A press which is not used during automatic operation can also be used as a manual press. It is unnecessary to stop the equipment by mold cleaning or the like. |
Product name: AcrossR2
| Product | Description |
|---|---|
 | A multi-product compatible model with a single body press. For conversion support, switching to other types is also possible in the shortest 30 minutes. By adopting a center turntable, we simplified the drive section and realized an efficient layout. |
Product name: Across 2 / Across 4 / Across 8
| Product | Description |
|---|---|
 | Custom correspondence model tailored to customer's needs. We will manufacture from the press capacity, mold size, product size, etc. to the color of the cover according to customer's request. |
Product name: AcrossH
| Product | Description |
|---|---|
 | A model corresponding to a hoop-like frame. Frames correspond to articles 1 and 2. It is also possible to manufacture according to existing gate cutting mold etc |
Manual press
| Product | Description |
|---|---|
 | It is possible to produce it according to the specifications and layout required by customers. We support every die size and press ability from trial production. In addition, various options such as hydraulic plunger and vacuum molding are available. Application: For prototype mold Overseas Extensive press capacity Hydraulic / vacuum degassing molding |
About other options
Hydraulic control · vacuum degassing molding / heat sink conveyance / automatic mold release / spray / auto cleaning ... others
In order to respond to various customer's requests, various option specifications are also prepared, so please consult us about anything. We will propose the optimum equipment to our customers by making full use of the accumulated technology in manufacturing mold manufacturing and sealing equipment.
Modification of peripheral equipment and existing equipment
Automated equipment
Name: Frame Loader
| Product | Description |
|---|---|
 | It is possible to produce from 2 sheets to loading frame for Conveyor. Automatic / semiautomatic etc. We support all specifications. |
Name: automatic inspection equipment
| Product | Description |
|---|---|
 | We manufacture inspection equipment such as chip misalignment, lead bending, printing on packages. |
Name: tableting machine
| Product | Description |
|---|---|
 | Automatic supply of powdered semiconductor sealing resin and tableting in pellet form. It is possible to correspond to the pellet shape to suit your needs. |
Name: Spiral flow
| Product | Description |
|---|---|
 | It is possible to test the spiral flow of resin inside the company and to investigate the cause of failure. |
Name: Resin Characteristic Inspection Machine
| Product | Description |
|---|---|
 | You will be able to have the standard value of gel time inside the company. Measurement becomes possible immediately when you are in trouble. |
Name: Frame cutting device
| Product | Description |
|---|---|
| Cut the reel-like lead frame into strips. Inline correspondence with mold equipment can also be produced. |
Name: TF device
| Product | Description |
|---|---|
 | It is the production of equipment to meet customer's needs. Laser markers and equipment with image inspection mechanism are also compatible. |
Equipment remodeling
Please consult us if there is a problem you need with existing equipment! !
Experience of Yield Improvement accumulated in Mold Manufacturing and Sealing Device Manufacturing · We will propose to customers by making full use of the productivity improvement improvement technology.
Semi-automatic, automated, man-hour reduction, safety improvement effect of manual equipment.
Please contact us for any improvements / modification work of existing equipment, anything.
Various other parts
Please contact us if you are looking for parts that are difficult to obtain, parts or devices for which there is no drawing or the model/maker is unknown.
